EX12PRO
Two-way bi-amp 12″ powered loudspeaker with 24-bit DSP, Bluetooth and 500W RMS (1050W peak) amplification.
Product Overview
Key Specifications
The EX12PRO is a two-way bi-amplified 12″ powered loudspeaker with 24-bit DSP and Bluetooth. Class D low-frequency and Class AB high-frequency amplification deliver 500W RMS (1050W peak) with a maximum SPL of 123dB and a 50Hz – 20kHz response, making it suited to live sound, portable PA and installed applications.
FEATURES
- High-performance engineering plastic enclosure — compact, lightweight and road-durable.
- Bi-amplified design: Class D low-frequency and Class AB high-frequency amplification, with a switching power supply.
- Built-in Bluetooth 4.0 module for wireless audio streaming.
- 24-bit DSP at 48kHz sampling, providing precise control over output gain, crossover and phase delay, with the ESD™ limiter for reliable driver protection.
- Four selectable presets tuned for full-range applications, covering a range of live and installed use cases.
| SPECIFICATIONS | |
| Type | Two-way bi-amp |
| Frequency Response | 50Hz – 20kHz |
| Sensitivity (1m/1W) | 93dB |
| Impedance | 4 ohms |
| Woofer | 12″, 75mm VC, 600Z |
| HF Driver | 1.35″ titanium |
| Maximum SPL | 123dB |
| Amplifier Type | LF Class D / HF Class AB |
| Amplifier Power (RMS) | LF 400W + HF 100W |
| Peak Power | LF 850W + HF 200W |
| THD | 0.05% |
| DSP | 48kHz sampling frequency, 24-bit |
| Bluetooth Module | Yes |
| Crossover | 1.9kHz |
| Protections | Over-temperature, overload, DC protection, over-voltage, low-voltage, soft start |
